The next data center is offshore.

Bluewater builds 200 MW campuses inside proven offshore concrete towers — cooled by the sea, powered from shore through rights that already exist — and maintained by technicians who take an elevator, not a submarine.

Scroll
0 MW
of IT capacity per tower, live at first byte — shore-powered through an existing coastal interconnection
0 sq ft
of data halls inside four concrete shafts — ≈3,000 liquid-cooled racks on a 525 ft structure
1.00 PUE
year-round in any climate — no chillers, zero freshwater consumed
0 yr
structure design life — the halls refit like the hardware inside them
~0× fewer
hardware failures in sealed nitrogen — measured by Microsoft’s Project Natick
The problem

The markets that need capacity most can no longer build it

Northern Virginia, Santa Clara, Phoenix, Atlanta — the grid queues run two to four years, the land is gone, the water is contested, and the neighbors are organized. Capital is available; buildable megawatts are not. Twenty-five miles offshore sits a site nobody is fighting over — a 3-acre seabed lease, 50–54 °F cooling in every season, no neighbors within earshot, and no interconnection queue.

2–4 yr

Grid queues

Interconnection waits in the major metros now exceed typical build schedules — power, not capital, sets the pace.

100+ ac

Land per campus

A 200 MW campus needs contested metro land, rezoning, and years of hearings. Offshore, the footprint is a 3-acre seabed lease.

0.5–1B gal

Water per year

Evaporative cooling at this scale consumes a small city’s water. The ocean takes the same heat without losing a gallon.

85 dB

The noise fight

Cooling-plant noise is now a leading cause of data-center opposition. At sea, the nearest bedroom window is 25 miles away.

Reference project · first vessel

A 50 MW floating AI campus — the barge is the building, the ocean is the heat sink

The near-term product is a jetty-moored, non-propelled heavy barge: ten identical 5 MW infrastructure blocks, direct-to-chip liquid cooling, and seawater heat rejection through isolated titanium exchangers. Bluewater delivers powered, cooled, secure halls. Customers bring the servers and GPUs. The 200 MW concrete tower remains the campus-scale platform; this vessel is how we put megawatts in the water first.

Bluewater 50 MW floating data-center barge, electrical topside, no cooling towers
Five-deck cutaway of the Bluewater barge showing IT halls over the cooling plant
Five decks, top to bottom: electrical topside, two 25 MW IT halls, mechanical plant, seawater and ballast. Heavy compute stays low in the hull.
Bluewater barge jetty-moored with shore power cables
Base case is jetty-moored on existing high-capacity power and fiber — not a greenfield “anywhere” claim.
Liquid-cooled AI hall with marine watertight subdivision
Upper and lower IT halls share the same 5 MW module geometry. Direct-to-chip liquid cooling; no raised floor in the base design.
Topside electrical equipment on the Bluewater barge
Topside is electrical and service only. Primary heat rejection is below deck. No chiller farm, no cooling towers.
50 MWIT capacity on the first vessel
10 × 5 MWStandardized infrastructure modules
Seawater HXTitanium isolation — raw seawater never enters the IT halls
Customer ITGPUs and servers stay on the tenant balance sheet
Depth
0 ft
Sea surface
+82 ft · Topsides

A working deck, lean topside crew

Everything above the waterline: 220 kV GIS, transformers, control room, helideck. The IT load is run from a shore NOC; a lean topside crew handles power, safety, and facility systems.

220 kVshore interconnection
Lean crewtopside ops + shore NOC
100–300 ft · The data halls

Fifteen decks of compute in every shaft

Four Gullfaks-class concrete shafts — 98 ft across at the base, 46 ft at the top — carry the entire 200 MW from day one. Halls are sealed in dry nitrogen; a pressurized core with passenger and 5-ton freight lifts keeps every rack an elevator ride away.

221,700 sq ftusable hall floor
≈3,000liquid-cooled racks
1 atmwalk-in access core
100–300 ft · Sealed nitrogen

The ocean is the cooling plant

Every megawatt lives inside the four shafts — ≈55,400 sq ft of usable hall per shaft across fifteen decks. Closed-loop liquid cooling hands heat to 50–54 °F seawater at the pump room; no chillers, no towers, no external growth modules.

1.05 PUEpumps only
N₂~1/8× failure rates
400 ft · The caisson

Gravity is the foundation

A cellular concrete caisson, ballasted down onto the seabed — no piles, no anchors, no heavy-lift vessels. The same gravity-based design has held ~30 North Sea platforms in place for fifty years. Pump rooms here draw 50–54 °F water year-round: the entire cooling plant is the ocean itself.

3 acrestotal seabed footprint
75–100 yrstructure design life
1.05 PUEno chillers, ever
5T FREIGHT
Elevator
DECK
Topsides lobby · air
Step in · 1 atm the whole way

Street clothes, not scuba gear

From the topsides lobby, a passenger lift and a 5-ton freight lift run the full height of each shaft. The entire core — lifts, stairs, refuge decks — is ordinary air at ordinary pressure. No divers, no decompression, ever.

5 tfreight lift — a full rack, crated
15deck stops per shaft
Decks 1–15 · The data halls

Racks ring the core on every deck

Step off at any deck: liquid-cooled racks ring the elevator core, denser as the shaft widens toward the base — from roughly 2,600 sq ft per deck at the top to 4,800 sq ft at the bottom. Cold plates take the heat straight to the risers you see running the height of the shaft.

120 kWAI-class racks, liquid to the plate
55,425 sq ftof halls per shaft
Every deck · The airlock

Two doors between air and nitrogen

The halls beyond the core are sealed in dry nitrogen — no oxygen, so no fire, no corrosion, no dust. On planned maintenance days a technician swings through the airlock with a breathing set; the rest of the year the racks run untouched, and fail roughly eight times less often for it.

N₂hall atmosphere
~8×fewer failures — Project Natick
Below deck 15 · Pump room

The whole cooling plant is this room

At the bottom of the shaft, seawater pumps and hull heat exchangers move the tower’s heat into 50–54 °F ocean — the machinery that replaces an entire chiller yard on land. The freight lift serves this deck too: every pump is swappable without a marine operation.

1.05PUE, any climate
0chillers, cooling towers, fans
The product · Floor plan

Looking down — the first floor of every shaft

Deck 1 at −112 ft: a sealed nitrogen hall around a one-atmosphere elevator core. Thirty-six liquid-cooled racks, dual CDUs, and a 4.5 ft perimeter service corridor — the same layout scaled up through fifteen decks as the shaft widens.

Ø 64′-0″ clear · 2,600 sq ft · 36 racks · 2.4 MW · EL. −112 FT FREIGHT 5 T · 10.5′ LIFT STAIR RISERS A/L A/L CDU CDU COLD AISLE HOT AISLE HOT AISLE COLD AISLE N₂ HALL PERIMETER SERVICE CORRIDOR · ≈4.5′ Ø 64′-0″ CLEAR Deck 1 — looking down Top data hall in every shaft · plan view 36 AI racks · 66 kW avg · 2.4 MW 1-atm core — freight + passenger lifts Airlocks into sealed N₂ hall Deck CDUs · liquid loop What you see Racks sit in a ring around the elevator core — not against the hull. A 4.5′ corridor runs the full perimeter for service and cable trays. Same plan repeats fifteen times as the shaft widens: Deck 15 is Ø85′ and 4.4 MW. Usable floor deducts core, risers, and airlocks.
Ø 64 ftclear inside liner
2,600 sq ftusable hall floor
36 racks2.4 MW · 66 kW avg
×15 decks→ 50 MW per shaft
Technology

Assembled, not invented

Every element of a Bluewater tower has decades of service history in another industry. Our work — and our patent-pending system — is the integration.

01 / STRUCTURE

Condeep-class concrete tower

A 525 ft gravity-based structure descended from ~30 North Sea platforms — slip-formed in a dry dock, towed to site floating, ballasted down in a season. Certified under existing DNV offshore-concrete rules. 75–100 year design life.

02 / ATMOSPHERE

Sealed nitrogen halls

No oxygen means no fire, no corrosion, no dust — the regime Microsoft’s Project Natick showed cuts hardware failures roughly eightfold. Technicians work from a one-atmosphere core and enter halls through airlocks on planned maintenance days.

N₂
03 / ACCESS

An elevator, not a submarine

Passenger and 5-ton freight lifts connect the surface deck to every data deck at ordinary atmospheric pressure. Any rack, in minutes, in street clothes — no divers, no decompression, no marine operation to swap a server.

04 / POWER

800 VDC, megawatt racks

High-voltage DC distribution runs the halls at rack densities today’s grid-tied buildings can’t reach — ready for 120 kW AI racks now and 1 MW-class racks over the structure’s life. Power arrives from shore; the halls are generation-agnostic if a future onsite source is ever added.

Heritage · Proof of scale

These shafts have been built before — more than twenty times

Gullfaks A’s four concrete shafts rising out of Gandsfjorden, Norway, in 1984–85 — the same four-shaft, 98 ft-base configuration Bluewater outfits as data halls. Slip-formed around the clock by 1,400 hydraulic jacks, the finished substructure was towed to sea floating and set down on the seabed, where it has operated since 1986. Nothing about the structure is new; only the payload is.

Gullfaks A's four concrete shafts under tow in Gandsfjorden with tower cranes and tugboats
Four completed shafts under tow — the tugboats alongside give the scale. Each shaft is wide enough to hold the fifteen data decks of one Bluewater module.
Aerial view of the slip-form deck during shaft construction, workers visible for scale
The slip-form deck from above — count the workers. Every data deck we outfit spans this circle.
Inside a Condeep shaft during construction with workers on scaffolding
Inside one shaft during construction — the volume that becomes fifteen decks of server halls.
630,000 tons
substructure weight at tow-out — moved across the fjord by nine tugboats
443 ft
of water at the Gullfaks field, where the structure has stood since 1986
~30 built
Condeep-class concrete platforms delivered 1975–1995 under DNV rules that still apply
31 years
Troll A’s shafts have stayed dry at 994 ft with crews working at the seabed
PHOTOS: NORSK OLJEMUSEUM — NORWEGIAN PETROLEUM MUSEUM
Cooling

The ocean is the chiller

Closed-loop liquid cooling carries heat from cold plate to hull heat exchanger; the sea does the rest. At 100–300 ft the water holds 50–54 °F every hour of every year — no heat waves, no derating, no evaporation.

Supply reaches the racks at ≈64 °F, returns at ≈95 °F, and leaves through the hull with a thermal plume that disperses within yards. The result is a 1.05 PUE in any climate — and a data center that is quiet on both sides of the waterline. No cooling towers or rooftop fans for neighbors who don’t exist; below the surface, Microsoft’s undersea deployment measured its sealed hull as quieter than the snapping shrimp around it.

RACK · COLD PLATE HULL HX 95 °F return 64 °F supply plume disperses sea 50–54 °F OPEN OCEAN
Power

Shore power first — no interconnection queue

Day one runs on an existing shore interconnection. The structure, halls, and cooling stay the same if a future onsite generation path is ever pursued — that decision waits for FID, licensing, and real economics, not the Series A story.

Land on grid rights that already exist. The tower’s 220 kV corridor connects at a retired coastal plant — berths like San Pedro and San Onofre — so day-one capital is ≈$2.3B and there is no multi-year interconnection queue. Topsides hold the GIS and transformers; the architecture stays open to later generation only if it clears licensing and cost.

≈$2.3Bday-one capital
220 kVexisting shore interconnection
0years in a new queue
220 kV GIS · topsides SHORE → 220 kV IMPORT
Advantages

Why the ocean is a better solution

3 ac

Seabed lease, not land

Replaces 100+ acres of contested metro land — and the rezoning fights that come with it.

0 gal

Water consumed

Closed-loop cooling rejects heat through the hull. No cooling towers, no evaporation, no refrigerant plant.

0

Queue position

Landed on interconnection rights that already exist — no multi-year wait for a new grid position.

24/7

Cool, every hour

50–54 °F water in every season. No heat-wave derating in exactly the hours compute is most valuable.

0

Pile drives, hammer blows

The base floats out and ballasts down — none of the piling noise that stalls offshore wind. In service the sealed hull is quieter than the seafloor’s own snapping shrimp (Natick, measured), with hydrophones keeping watch.

Roadmap

From engineering to first byte

Now

50 MW barge — FEED

Reference vessel: hull survey, class, vendor quotes, power site, and anchor-customer work on the jetty-moored 50 MW platform.

2027

Tower FEED & permits

Front-end engineering with Dr.techn. Olav Olsen, environmental studies, seabed lease for the 200 MW campus.

2028–29

Construction

Slip-forming in a proven heavy-marine dry dock; halls outfitted and topsides set at the quay.

2030

Tow & install

Single-season float-out, tow to site, ballast-down — standard Condeep practice for fifty years.

2031

First byte — 200 MW

All four shaft halls live at arrival on shore power; tenants lease into nameplate capacity.

2033+

Fleet scale

Fully leased nameplate — then replicate the platform. Tower #2 from cash flow and refinance, not a construction-site expansion.

Who we are

Nobody has built this project. Everyone on this bench has built its parts.

Bluewater is a first-of-a-kind combination of proven pieces — so the team is drawn from the people who delivered each piece: North Sea concrete platforms, hyperscale data centers, large-scale power, and multi-billion-dollar infrastructure financings.

Founder & Developer
20+ years founding and developing projects in the defense and energy sectors
The founder’s role: identify the convergence, control the sites and permits, hold the capital plan together — and recruit the people who have each built their piece of it before.

Offshore structures

Senior alumni of the Condeep design-and-build lineage: gravity-base design, marine construction, DNV classification.

Hyperscale data centers

Former capacity-delivery executives from the largest cloud operators, with multiple campuses delivered end to end.

Power & transmission

Utility leadership and developers of large generation and transmission — the people who land interconnection and keep megawatts firm.

Project finance

Veterans of multi-billion-dollar infrastructure financings, including non-recourse debt raised from infrastructure lenders.

Permitting & government

Former federal offshore-permitting officials and environmental leads — the people who have run the reviews we will file.

First-option design partner: Dr.techn. Olav Olsen (Artelia) — the Norwegian firm behind the original Condeep platforms — for front-end engineering. Advisory and executive seats are announced as they sign; the full roster is disclosed in the investor data room.
Investors & partners

Buildable megawatts are the scarcest asset in computing.

Bluewater is raising development capital to de-risk the 50 MW reference vessel — naval architecture, class, hull, interconnect, and an anchor customer — and to keep FEED moving on the 200 MW concrete campus. A non-confidential teaser is available on request; the full deck and data room follow for qualified investors.
